Universal Plug Connector 2EDGK-5.0-08P-14-00A (H) Pluggable Terminal Block

Product Description
Universal Plug Connector 2EDGK-5.0-08P-14-00A (H) Pluggable Terminal Block



Universal Installation Suitable For Many Occasions Plug Connector 2EDGK-5.0-08P-14-00A (H)



Features:

The cross section of hard wire is 1.0~2.5mm²

The cross section of flexible wire is 1.0~2.5mm²

Connecting wire cross section 28~12AWG

The strip length is 7mm

Electrical parameter UL

Rated voltage (B) 300V

Rated voltage (D) 300V

Rated current (B) 15A

Rated current (D) 10A

Environmental matters comply with REACH/RoHS

The contact material is copper alloy

The metal surface of the connection point is tinned

Tinned metal surface in contact area

Insulation material PA66

Insulating materials Group Ⅰ



Specifications:

Connection mode Screw connection
Screw head drive mode Flat-head
screwdriver
Thread
M3
Plug or unplug Yes
