PIN S6775 Electronic Gas Analyzer Photodiode , Silicon Infrared Combustible Gas Detector

Product Description
S6775 Silicon PIN Photodiode Photosensitive Area SIP Encapsulation



Plastic SIP (Single Wire Package)

The S6775 has a large photosensitive area and is packaged in a plastic SIP, which shields visible light and is suitable for detecting near-infrared wavelengths. It is characterized by high sensitivity, high-speed response, and large photosensitive area.


Product Features
● High-speed response
● High sensitivity
● Block visible light
● Plastic package: 7 × 7.8 mm
● Large photosensitive area: 5.5 × 4.8 mm



Datasheet:

Spectral response range 700 to 1100 nm
Peak Sensitivity Wavelength (Typical) 960 nm
Sensitivity (typ) 0.68 A/W
Dark current (max) 10000 pA
Junction capacitance (typ.) 40 pF
Cutoff frequency (typ.) 15 MHz
Measurement Conditions Typ. Ta=25 ℃, unless otherwise noted, Photosensitivity: λ=960 nm, Dark current: VR=10 V, Cutoff frequency: VR=10 V, Terminal capacitance: VR=10 V, f=1 MHz
