IC694MDL930 New GE Fanuc Isolated Relay Output Module

IC694MDL930 New GE Fanuc Isolated Relay Output Module

$491.00  $241.00
Save: 51% off


Product Number: IC694MDL930
Model: Isolated Relay Output Module
Manufacturer: Siemens
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months

Specifications

Rated Voltage24 volts DC, 120/240 VAC (nominal - see the following table for exceptions)
Operating Voltage5 to 30 volts DC

5 to 250 VAC, 50/60 Hz
Outputs per ModuleEight isolated outputs
Isolation:
        Field to Backplane and to Frame Ground250 VAC continuous; 1500 VAC for 1 minute
        Point to Point250 VAC continuous; 1500 VAC for 1 minute
Maximum Load4 Amps resistive maximum per output

2 Amps pilot duty per output

20 Amps maximum per module for UL installations
Maximum Load depends on the ambient temperature as shown below
Minimum Load10mA
Maximum Inrush5 Amps
On Response Time15ms maximum1
Off Response Time15ms maximum1
Power Consumption6mA (all outputs on) from 5 volt bus on backplane

70mA (all outputs on) from relay 24V bus on backplane

Note:
  1. When this module is used with DC power supply IC695PSD040 or PSD140, special precautions should be taken because dropouts in the source voltage will be seen by this module and may cause relay dropouts.

  • Availability : In Stock
  • Estimated Lead Time : Usually Ships in 7 - 10 Working Days
  • Shipping Weight : 2 Kg
