Model | 1747-L532 |
Memory Size
| 16K Words |
I/O Capacity | 4096 discrete |
Remote I/O capacity | Processor memory and chassis power limit up to 4096 inputs and 4096 outputs |
Maximum Chassis/Slots | 3 Chassis/30 Slots of I/O |
Standard RAM
| Capacitor - 2 weeks? optional lithium battery - 5 years
Lithium battery 2 years Capacitor - 30 minutes minimum |
Memory Back-up Options | Flash EPROM |
Status Indicators | Run, CPU Fault, Battery Low, Forced I/O, DH-485, RS-232 |
Power Supply Loading | 500 mA at 5V dc |
175 mA at 24V dc |
Clock/calendar accuracy?
| ?54 sec./month at 25 ?C (77 ?F); ?81 sec./month at 60 ?C (140 ?F) |
Program scan hold-up time after loss of power | 20 ms...3 s (dependent on power supply loading) |
Noise Immunity
| NEMA Standard ICS 2-230 |
Ambient Temperature Rating
| Operating: 0?C to +60?C (32?F to 140?F) Storage: -40?C to +85?C ( 40?F to 185?F) |
Humidity | 5 to 95% without condensation |
Shock (operating) | 30 g |
Vibration | Displacement: .015 in., peak-to-peak at 5 to 57 Hz |
Acceleration: 2.5Gs at 57 to 2000 Hz |
Certification | UL Listed Industrial Control Equipment for Class I, Division 2, Groups A, B, C, D Hazardous Locations |
C-UL Listed Industrial Control Equipment for Class I, Division 2, Groups A, B, C, D Hazardous Locations |
CE? European Union 89/336/EEC EMC Directive, compliant with: EN 50082-2 Industrial Immunity EN 50081-2 Industrial Emissions or EN 61000-6-2 Industrial Immunity EN 61000-6-4 Industrial Emissions European Union 73/23/EEC LVD Directive, compliant with safety related portions of: EN61131-2 Programmable Controllers |
C-Tick, Australian Radio Communications Act, compliant with: AS/NZS 2064 Industrial Emissions |
