HTG3535CH Integrated Circuit Temperature Sensor NTC Digital Temperature And Humidity Sensor

Product Description:

HTG3535CH Analog Voltage Output T/H Sensor Module



Features:

Based on Humirel's humidity capacitors, the HTG3535CH is a module with an integrated temperature and humidity output interface, specifically designed for OEM customers where reliable, precise measurements are required. With micro control chip, humidity is linear voltage output, with 10Kohm NTC temperature output. HTG3535CH can be used in mass production and where high measurement accuracy is required.

Air conditioning, HVAC, refrigerator, weather station, machine station, communication room, cultivation room, maintenance room, drying cabinet and so on.

Environmental protection product

Full range interchangeability

High reliability and long term stability

Accuracy: + / - 3% RH @ 55% RH

The supply voltage must be within the specified range

Through 10Kohm NTC resistance measurement temperature accuracy is +/-1% direct output in 5Vdc power supply output voltage value is 1~ 3.6V can be measured 0~ 100%RH relative humidity



Specifications:

Storage temperature -20-120℃
Operating voltage 20Vdc
Humidity range RH0-100%
Temperature range -40-110℃
Maximum output current 5mA
Maximum power consumption 25nW
