Part Number: FEN-21Type: Resolver Interface Module
Resolver Interface Module, PTC/KTY support, 1-Resolver & 1-TTL In, 1-Encoder Emulation Out
Technical Data
General- Max. power consumption: 350 mA at 24 V (Max. combined power consumption of encoders, latches and cabling 5W)
- Degree of protection: IP20
- Ambient conditions: The applicable ambient conditions specified for the drive in its Hardware Manual are in effect.
Connectors- 20-pin
- 9-pin D-sub plug
- 15-pin D-sub plug
- 9-pin D-sub socket
- 6-pin header
TTL encoder input (X51)
- Output voltages:
- +5.5 V DC -5%, -8%, 180 mA
- +24 V DC ±15%, 150 mA together with digital inputs
- +5.5 V and +24 V combined maximum power is 3.6 W - CH A, CH B, CH Z: RS-422/485, differential, 500 kHz (max)
- Maximum cable length:
- 30 m with a 5 V encoder (0.5 mm² cable for power supply)
- 60 m with a 5 V encoder (two parallel 0.5 mm2 cables for power supply)
- 100 m with a 10Ö30 V TTL incremental encoder - Performance:
- Speed range: -32768Ö32767 rpm
- Speed resolution: 0.04 RPM (24 bits)
- Position resolution: 16 M / rev (24 bits)
- Position accuracy: 4x pulse count / rev - Isolated together with digital inputs
Resolver Interface
- Output voltage: (AC) 4...12 Vrms, 100 mA max.
- Sine & cosine differential inputs 2...7 Vrms
- KTY84 or PTC thermistor input
- Performance:
- Position resolution: 24 bit
- Speed resolution: 24 bit - Maximum cable length: 100 m
- Isolated together with TTL encoder emulation output
TTL encoder emulation output (X53)
- Supports emulation of TTL incremental encoder, 1Ö65535 pulses / rev, reference mark
- CH A, CH B, CH Z: RS-422/485, 500 kHz (max)
- Maximum cable length: 100 m
- Performance
- Speed range: -32768Ö32767 rpm
- Position resolution: 4x pulse count / rev - Isolated together with absolute encoder input
Digital inputs for position latch (X54)
- Output voltage: +24 V DC ±15%, short-circuit proof
- Signal levels: < 5 V = 0, > 15 V = 1
- Isolated together with TTL encoder input
- Availability: In Stock
- Estimated Lead Time: Usually Ships in 1 - 10 Working Days
- Shipping Weight: 2 Kg
