Acid C-100 Acetic Acid Sensor 3 Electrode Electrochemical

Product Description
Acid/c-100 Acetic Acid Gas Sensor Acid Safety and Process Control



Performance data recorded at 20 – 25 °C, 30 - 50% RH, 900 - 1100 mbar For further information about usage of Membrapor sensors, see application note MEM1. The data contained in this document is for guidance only. Membrapor AG accepts no liability for any consequential losses, injury or damage resulting from the use of this document or from any omissions or errors herein. Customers should test under their own conditions to ensure that the sensors are suitable for their own requirements.



Acetic Acid Gas Sensor Acid/C-100
RCOOH Gas Sensor in Compact Housing
Key Features
• Selective Measurement of Organic Acids
Applications
• Safety and Process Control
• Continuous Air Quality Monitoring



Datasheet:

Relative Humidity Range 15 % to 90 % RH non-condensing
Temperature Range -10 °C to 50 °C
Pressure Range Atmospheric ± 10%
Pressure Coefficient N.D.
Humidity Effect None
Expected Operation Life 2 years in air
Expected Long Term Output Drift in air < 2 % signal loss per month
Storage Life 6 months in container
Rec. Storage Temperature 5°C - 20°C
Warranty Period 12 months from date of dispatch
