5 INCH-D1-MV-MINI Amplified MEMS Based Pressure Sensor Linear Output with Amplitude Correction

Product Description:

5 INCH-D1 MV-MINI Pressure Sensor With Amplifying Zero Position And Amplitude Correction



Features:

Pressure sensor with amplified zero and amplitude correction millivolt output, based on proprietary technology, 5inCH-D1-MV-Mini to reduce all output offsets or common-mode errors. The model provides a calibrated millivolt output with superior output offset characteristics. Compared with the traditional compensation, the output offset error, preheating stability, long time stability and position sensitivity are reduced due to temperature variation. In addition, the sensor employs a silicon, micromechanical, stress concentrated reinforced structure to provide a very linear output for measuring pressure. These calibrated and temperature compensated sensors provide stable output over a wide range of temperatures. This series is suitable for non-corrosive, non-ionic working fluid, such as air, dry gas, etc. The output of the device is proportional to the supply voltage, and any operation with a DC supply voltage up to +16 V is acceptable

Specifications:



Output signal analog voltage
Features with temperature compensation
Operating temperature -13 to 185 F (-25 to 85 C)
Type of pressure Differential
Product Category Pressure Sensors
