MP-4 Methane Natural Gas Biogas Planar Semiconductor Gas Sensor Output Signal

Product Description
MP-4 Methane Natural Gas Biogas Planar Semiconductor Output Signal



MP-4 combustible gas sensor (gas sensor, natural gas sensor) adopts multi-layer thick film manufacturing process. The heater and metal oxide semiconductor gas sensing layer are respectively made on both sides of the micro Al2O3 ceramic substrate, and are packaged in a metal shell. The conductivity of the sensor changes when the detected gas is present in the ambient air. The higher the concentration of this gas, the higher the conductivity of the sensor. This change in conductivity can be converted into an output signal corresponding to the gas concentration using a simple circuit.



Datasheet:

Loop voltage ≤24V DC
Heating voltage 5.0V±0.1V AC or DC
Load Resistance Adjustable
Heating resistance 85Ω±15Ω (room temperature)
Heating power consumption ≤350mW
Temperature Humidity 20℃±2℃；55%±5%RH
Standard Test Circuit Vc:5.0V±0.1V； VH:5.0V±0.1V
Preheat time Not less than 48 hours
