Part Number: 1783-MS06TModel: Switch
Manufacturer: Allen Bradley
Technical Specifications
- Description: Stratix 8000 managed switch, Layer 2, 6 ports
- Inrush current, max: 2.0 A
- Power input, max: 2 A max @ 18 ... 60V DC, CL 2/SELV
- Alarm relay, max: 1 A max @ 30V DC, CL 2/SELV
- Power consumption, max (Expansion module power not included): 15.1 W
- Power dissipation: 15.1 W
- Isolation voltage:
75V (continuous), basic insulation type, power to ground, power to network channels, and power to alarm
No isolation between individual Ethernet ports
No isolation between console port and system
Type tested at 1000V AC for 60 s - Wire size, Ethernet connection (1): RJ45 connector according to IEC 60603-7, 2- or 4-pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 24702
- Wire size, DC power and alarm connections: 0.5??0.8 mm2 (20??18 AWG) solid or stranded copper wire rated at 90??C (194 ??F) or greater, 1.2 mm (3/64 in.) insulation max
- Wire size, ground connection: 3.3??5.3 mm2 (12??10 AWG) solid or stranded copper wire rated at 75??C (167??F) or greater
- Screw torque, power and alarm terminals: 0.23 N?m (2.0 in?lb)
- Wiring category (2):
2 - on alarm ports
2 - on power ports
2 - on Ethernet ports - Enclosure type rating: None (open-style)
- Pilot duty rating: Not rated
- North American temp code: T4
- IEC temp code: T4
- Availability: In Stock
- Estimated Lead Time: Usually Ships in 7 - 10 Working Days
- Shipping Weight: 2 Kg
