| FM (US) | /FU1 | 4-20mA:
[Intrinsically safe approval/non-incendive approval]
Applicable standard: Class 3600:2011, Class 3610:2015, Class 3611:2004, Class 3810:2005,
ANSI/ISA-60079:2013, ANSI/ISA-60079-11:2014, NEMA 250:2003, ANSI/IEC 60529:2004 (R2011)
Intrinsically safe for
Class I, II, III Division 1, Groups A, B, C, D, E, F, G, T5 ... T4
Class I Zone 0 AEx ia IIC T5 ... T4
Non-incendive for
Class I, II, Division 2, Groups A, B, C, D, F, G, T5 ... T4
Class III, Division 1 T5 ... T4
Class I Zone 2 Group IIC T5 ... T4
Ambient Temperature: -40 tp 70??C for T4, -40 to 50??C for T5
Enclosure Type 4X, IP66/IP67 in accordance with only IEC 60529
Entity Parameters:
Intrinsically safe for
Supply/Output circuit: Ui30V, li=200mA, Pi=0.1W, Ci=22nF, Li=0mH
Sensor circuit: Uo=6V, lo=90=mA, Po=135mW, Co=10??F, Lo=3.9mH
Non-incendive for
Supply/Output circuit: Ui=30V, Ci=22nF, Li=0mH
Sensor circuit: Uo=6V, Io=90mA, Po=135mW, Co=10??F, Lo=3.9mH
Dielectric strength: 500 V a.c.r.m.s., 1 min
[+, -, C, 1, 2, 3, 4, 5] to Earth terminal
[+, -, C] to [1, 2, 3, 4, 5]
[Explosionproof approval]
Applicable standard: Class 3600, Class 3615, Class 3810, ANSI/NEMA250
Class I, Division 1, Groups A, B, C, D.;
Class II/III, Division 1, Groups E, F and G.
"FACTORY SEALED, CONDUIT SEAL NOT REQUIRED."
Enclosure Ratings: TYPE 4X
Temperature Class: T6
Ambient Temperature: -40 to 60??C (-40 to 140??F)
Electrical Connection: 1/2 NPT female(1) |
