XGZP701DB1R Piezoresistive Pressure Transmitter , XGZP Pressure Sensor 700kPa

Product Description:

XGZP701DB1R XGZP Type -100kPa ~ 10kPa... 700kPa Piezoresistive Pressure Sensing Element



Features:

XGZP piezoresistive pressure sensor is a pressure sensor suitable for biomedical, automotive electronics and other fields, the core of which is

A silicon piezoresistive pressure sensitive chip processed by MEMS technology. The pressure-sensitive chip consists of an elastic membrane and four integrated on the membrane

The four varistors form a Wheatstone bridge structure. When pressure is applied to the elastic film, the bridge creates a bridge with the pressure applied

The force is linearly proportional to the voltage output signal.

The XGZP pressure sensor is an OEM component packaged in standard SOP6 and DIP6 format, which is available in surface mount or dual format

Install in line mode

Good linearity, repeatability and stability, high sensitivity, convenient for users to use op-amp or integrated circuit for output and temperature drift debugging

And compensation.

Application field

electronic sphygmomanometer, ventilator, oxygen generator, monitor and other medical fields

Tire pressure gauge, MAP, steering power assist, brake power assist and other automotive electronics

Massager, massage chair, air mattress and other sports and fitness equipment field

Washing machine, beer machine, coffee machine, emergency lights, vacuum cleaner, water purifier, pressure instrument, pneumatic components and other fields



Specifications:

Measurement medium air
medium temperature (25±1) ℃
ambient temperature (25±1) ℃
Vibration 0.1g(1m/ S2)Max
humidity (50%±10%) RH
power supply (5±0.005) V DC
