Weintek MT8071iE Human Machine Interface

Weintek MT8071iE Human Machine Interface

$390.00  $214.00
Save: 45% off


Part Number: MT8071iE

Specification
  • Display
    Display: 7" TFT
    Resolution: 800 x 400
    Brightness (cd/m2): 400
    Contrast Ratio: 800:1
    Backlight Life Time: >30,000 hrs.
    Colors: 16.7M
    LCD Viewing Angle (T/B/L/R): 80/60/80/80
  • Touch Panel
    Type: 4-wires Resistive type
    Accuracy: Active Area Length(X)??2%, Width(Y)??2%
  • Memory
    Flash: 128 MB
    RAM: 128 MB
  • Processor
    32-bit RISC 600MHz
  • I/O Port
    USB Host: USB 2.0 x 1
    Ethernet: 10/100/1000 Base-T x 2
    COM 1: RS-232
    COM 2: RS-485 2W/4W
    COM 3: RS-485 2W/RS-232*(1)
  • RTC
    Built-in
  • Power
    Input Power: 24??20%VDC
    Power Isolation: Built-in
    Power Consumption: [email protected]
    Voltage Resistance: 500VAC (1 min.)
    Vibration Endurance: 10 to 25Hz (X, Y, Z direction 2G 30 minutes)
  • Specification
    PCB Coating: Yes
    Enclosure: Plastic
    Dimensions WxHxD: 200.3  x 146.3 x 34 mm
    Panel Cutout: 192 x 138 mm
    Mount: Panel mount
  • Environment
    Protection Structure: UL Type 4X (indoor use only) / NEMA4 / IP65 Compliant Front Panel
    Storage Temperature: -20?? ~ 60??C (-4?? ~ 140??F)
    Operating Temperature:     -0?? ~ 50??C (32?? ~ 122??F)
    Relative Humidity: 10% ~ 90% (non-condensing)
  • Certificate
    CE: CE marked
    UL: cULus Listed
    ATEX: ATEX Zone 2/22 Category 3 G/D
  • Software
    EasyBuilder Pro
    Built-in EasyAccess 2.0

  • Availability: In Stock
  • Estimated Lead Time: Usually Ships in 1 - 5 Working Days
  • Shipping Weight: 3 Kg

Add to Cart:

  • Model: MT8071iE
  • 7 Units in Stock


Processing Time
  • Ships in 24 hours: Processing Time is guaranteed to be shorter than 24 hours.
  • Typical Processing Time: 3 - 12 days
