TRD-GK600-RZ New Koyo Encoder

Encoder Type Incremental
Duty Type Heavy
Pulse Per Revolution 600
Input Voltage (VDC) 10-30
Output Form Push-Pull (Totem Pole)
Signal Format Quadrature (2-Phase Output) + Home Position
Output From Back
Shaft Solid
Shaft Diameter (mm) 10
Diameter (mm) 78
Depth (mm) 60
Mounting Pitch (mm) 66
Cable Length (meter) 2.00
Connector Type Tinned Ends
Protection Level IP65 (Waterjet Proof)
Mounting Screws Included
Short Circuit Protection Yes
Reverse Origin Action Positive Logic (Active High)
Total Shaft Length (mm) 22.0
Usable Shaft Length (mm) 15.0
