TGS5141 Button Carbon Monoxide Sensor (CO sensor)

Product Description:

TGS5141 Button Carbon Monoxide Sensor (CO sensor)



Features:

The CO sensor is a battery-operated electrochemical sensor developed by Figaro. It uses a special electrode instead of the water storage device. Because of the removal of the water storage device used in the TGS5042, the TGS5141 is reduced to only 10% of the size of the TGS5042. Its ultra-small size makes it an ideal choice for portable carbon monoxide detectors, miniature residential carbon monoxide detectors, and multipurpose fire detectors. OEM customers will find it possible to print data for each sensor individually through each sensor's barcode, allowing users to avoid costly gas calibration procedures and also allowing individual sensors to be tracked.

subminiature

Battery operated

High selectivity/repeatability for carbon monoxide

It has high linear output characteristic for carbon monoxide

Easy to calibrate

Long service life

Obtain UL certification

Meets UL2034 and RoHS requirements



Specifications:

Humidity range 5 ~ 99%RH (no condensation)
Response time (T90) 60s
Storage conditions -10˚C to +50˚C
net weight about 2.5g
