Part Number: RTT80-T1SSKNAFD-M2L1Model: Temperature Transmitter
Manufacturer: Foxboro
Features
- Superior accuracy and long term stability from microprocessor-based technology.
- Registration to HART Protocol Revision 7 (HART 7) digital communications is standard.
- Available with or without SIL certification.
- One unit configurable for a variety of Thermocouple (TC) and Resistance Temperature Detector (RTD) inputs.
- Supports 2-, 3-, or 4-wire RTDs.
- Allows average or difference measurement.
- Automatic sensor backup - a second sensor starts measuring temperature if the primary sensor is not functioning correctly.
- Temperature-dependent switching between sensors used in different measuring ranges.
- Drift warning message or alarm if the deviation between sensor 1 and sensor 2 is less than or greater than a predefined limit value.
- Thermocouple cold junction compensation.
- Galvanic isolation 2 kV input to output.
- Rich on-board diagnostics.
- Optional digital indicator.
- Available as a basic module that can mount to a surface or DIN rail, or in explosion-proof universal or dual compartment housings for remote mounting, and integral sensor and thermowell mounting.
- Available with a wide selection of sensors and thermowells.
- Configurable failsafe mA value.
- Maximum/minimum temperature logging.
- Conforms to applicable European Union Directives (product marked with ??CE?? logo).
- Electromagnetic compatibility in accordance with all relevant requirements of EN 61326 and NAMUR NE21.
- Meets many testing agency requirements for hazardous area installations.
- Standard two year warranty.
- Estimated Lead Time: 6 - 8
- Shipping Weight: 2 Kg
