New Rosemount 65 RTD Temperature Sensor 0065J01D0080D0400T48

Part Number: 0065J01D0080D0400T48
Model: 65 RTD Temperature Sensor
Manufacturer: Rosemount

Time Constant / Response: 9 seconds maximum required to reach 50% sensor response when tested in flowing water according to IEC 751:1983, Amendments 1 and 2
Insulation Resistance: 1,000 MO minimum insulation resistance when measured at 500 Vdc and at room temperature
Calibration Options: IEC 751 Class A accuracy; Calibration schedule with Callendar-Van Dusen constants; MID custody transfer calibration

Industry-standard sensor per IEC 751 with single or dual element design offers reliable and flexible performance
Resilient sensor withstands high vibration industrial applications
DIN-style sensor connection heads allow for quick mounting and replacement
Sensor selections cover a wide range of temperatures from –321 to 1112°F (–196 to 600°C) to meet process demands
Terminal block, flying leads and spring-loaded threaded adapters enable remote or integral mounting configuration
Callendar-Van Dusen constants allow for transmitter-sensor matching and provide the highest level of accuracy
Optional Class A accuracy ensures critical temperature measurement points meet tolerance standards and accuracy
Option for thermowell assembly increases protection from corrosive environments
Measurement Instrument Directive (MID) calibration options for custody transfer applications
Global hazardous location approvals meet local requirements

Estimated Lead Time: 5 - 7 days
Shipping Weight: 2 Kg
