New Rosemount 2088-G0A22A1 Pressure Transmitter 4-20mA 1/2" NPT

Manufacturer : Rosemount
Product No. : 2088-G3A22A1
Product type : 2088 Pressure Transmitter
2088 : Pressure Transmitter
Measurement type : G = Gage
Pressure ranges : 3 = –14.7 to 800 psi (–1,01 to 55,2 bar)
Materials of construction : 22 = 316L SST process connection, 316L SST isolating diaphragm, Silicone fill fluid.
Process connection : A = 1/2–14 NPT female
Conduit entry : 1 = 1/2–14 NPT
Power supply effect : Less than ±0.005% of calibrated span per volt change in voltage at the transmitter terminals
General specifications : Tested to IEC 801-3
Power supply : External power supply required. Transmitter operates on 10.5–42.4 Vdc with no load (5.8-28 V for Low Power). Reverse polarity protection is standard.
Humidity limits : 0–100% relative humidity

One year guarantee
