MPX2100A 0-100 Kpa (0-14.5Psi) With Compensatory Pressure Sensor

Product Description:

MPX2100A 0-100 Kpa (0-14.5Psi) With Compensatory Pressure Sensor



Features:

The MPX2100 series device is a silicon piezoresistive pressure sensors providing a

highly accurate and linear voltage output — directly proportional to the applied pressure.

The sensor is a single, monolithic silicon diaphragm with the strain gauge and a thin–film

resistor network integrated on–chip. The chip is laser trimmed for precise span and offset

calibration and temperature compensation.



• Temperature Compensated Over 0°C to +85°C

• Unique Silicon Shear Stress Strain Gauge

• Easy to Use Chip Carrier Package Options

• Available in Absolute, Differential and Gauge Configurations

• Ratiometric to Supply Voltage

• ±0.25% Linearity (MPX2100D)



Application Examples

• Pump/Motor Controllers

• Robotics

• Level Indicators

• Medical Diagnostics

• Pressure Switching

• Barometers

• Altimeters

Figure 1 illustrates a block diagram of the internal circuitry on the stand–alone

pressure sensor chip.



Specifications:

Overpressure(8) (P1 > P2) Pmax 200 kPa
Burst Pressure(8) (P1 > P2) Pburst 1000 kPa
Storage Temperature Tstg –40 to +125 °C
Operating Temperature TA –40 to +125 °C
Pressure Range(1) POP 0 — 100 kPa
Supply Voltage(2) VS — 10 16 Vdc
Supply Current Io — 6.0 — mAdc
Full Scale Span(3) MPX2100A, MPX2100D VFSS 38.5 40 41.5 mV
