ME4-NO2 Nitrogen Dioxide Gas Sensor 0 - 20ppm in Mine

Product Description
ME4-NO2 Nitrogen Dioxide Sensor 2 Years Life



ME4-NO2 sensor is a constant potential electrolytic NO2 sensor. The corresponding redox reaction between NO2 and O2 occurs on the working electrode and the counter electrode, and the charge is released to form a current. The magnitude of the generated current is proportional to the concentration of NO2. The concentration of NO2 can be determined by testing the magnitude of the current.



Main application
Widely suitable for the detection of nitrogen dioxide in industry, mine and environmental protection



Specification:

Resolution 0.1ppm
Response time (T90) <30s
Load resistance (recommended) 10Ω
Bias 0mV
Repeatability ＜2﹪Output value
Stability (/month) ＜2﹪
Zero drift (-20℃-40℃) 0.2ppm
Temperature range -20℃~50℃
Humidity range 15﹪-90﹪RH
Pressure range Standard atmospheric pressure ±10%
Detection life 2 years (in air)
