Part Number: LP-25066Model: Lightning Protector
Manufacturer: Prosoft Technology
Overview
The LP-25066 lightning protector is designed for use externally to an enclosure with any bulkhead fitting. The connectors are a standard N jack plug to a standard N jack BH connector. The bulkhead fitting can be connected to any standard N type connector extension cable.
Features and Benefits
- Multi-strike capability
- Fully weatherized housing
- Low throughput energy
- DC blocked
Specifications
- Frequency Range: 2000 - 6000 MHz
- Insertion Loss: 0.1 dB
- RF Power: 10 Watts
- Temperature Operating/Storage: -40?? C to +85?? C (-40?? F to 185?? F)
- Relative Humidity: 0 to 100% condensing
- Surge Throughput Energy: = 0.5000 ??J
- VSWR: 1.2:1
- Estimated Lead Time: 6 - 9
- Shipping Weight: 2 Kg
