Product Number: IDP10-T22C01F-L1
Model: IDP10 Pressure Transmitter
Manufacturer: Foxboro
Features
- Silicon strain gauge sensors successfully field proven in many thousands of installations.
- Simple, elegant sensor packaging, with very few parts achieves exceptionally high reliability.
- Transmitter available with traditional or low profile structures (see photos above).
- Aluminum housing has durable, corrosion resistant epoxy finish; 316 ss housing also available; both meet NEMA 4X and IP66 ratings.
- Can be provided as a sealed measurement system with numerous configurations of direct connect or capillary connected seals available.
- SIL2-Certified Transmitter offered as an option.
- Optional mounting bracket sets allow pipe, surface, or manifold mounting of transmitter.
- Remote configuration with HART communication protocol in a single loop or multidrop mode; or locally via optional LCD indicator.
- Multi-marking is available for FM, CSA, and ATEX intrinsically safe installations. The user determines and permanently marks on the data plate the certification to be applied.
- User-entered cutoff point from 0 to 20% of maximum flow.
- Dual Seal certified by CSA to meet ANSI/ISA 12.27.01-2003 requirements.
- Industry standard 316L ss, Co-Ni-Cr, Nickel alloy1, Monel, or Tantalum sensor materials, depending on transmitter structure.
- Equivalent to Hastelloy® C. Hastelloy is a registered trademark of Haynes International, Inc
- Estimated Lead Time: 8 - 10
- Shipping Weight: 5 Kg
