Product Number: EJA430E-JAS4G-917DB/D4/KU22Model: EJA430E Gauge Pressure Transmitter
Manufacturer: Yokogawa
Overview
The EJA-E series of transmitters is Yokogawa's most recent evolution of the DPharp family. Released in 2012, it combines the ruggedness and success of the work-horse EJA-E series with the performance of the thoroughbred EJX-A series to deliver the type of product you have come to expect from Yokogawa.
The EJA430E is a traditional-mount gauge pressure transmitter in the series.
EJA430E features include:
- 0.055% Accuracy (0.04% Accuracy optional)
- 0.1% Stability per 10 years
- 90 ms Response Time
- Exida and TUV SIL 2/3 Certified
- Local Parameter Setting (LPS)
Specifications
- Measurement Types
Primary Variable: Gauge Pressure - Reference Accuracy
Primary Variable:
??0.055% of Span
??0.04% of Span (with /HAC option) - Stability (All Normal Operating Conditions)
Primary Variable: ??0.1% of URL per 7 years - Response Time
Primary Variable: 90ms - Rangeability
Primary Variable: 100:1 - Burst Pressure (Absolute)
EJA510E:
Wetted Parts code S: 10,000 psi
All other Wetted Parts: 6,800 psi - Specification Conformance
EJA-E Series: ??3s
- Estimated Lead Time: 8 - 9
- Shipping Weight: 5 Kg
