Part Number: EJA110E-DLH4G-912EAModel: EJA110E Differential Pressure Transmitter
Manufacturer: Yokogawa
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
Ordering Information
Model | EJA110E | Differential pressure transmitter |
Output signal | -D | 4 to 20 mA DC with digital communication (BRAIN protocol) |
Measurement span (capsule) | L | 0.5 to 10 kPa (2.0 to 40 inH2O) (For Wetted parts material code M, H, T, A, D, B and W) |
Wetted parts material(1) | H# | Cover flange and process connector: ASTM CF-8M(2) Capsule: Hastelloy C-276(3) Capsule gasket: PTFE Teflon Vent/Drain plug: 316 SST |
Process connections | 4 | with 1/2 NPT female process connector |
Bolts and nuts material | G | 316L SST |
Installation | ?-9 | Horizontal piping and left side high pressure |
Amplifier housing | 1 | Cast aluminum alloy |
Electrical connection | ?2 | 1/2 NPT female, two electrical connections without blind plugs |
Integral indicator | E | Digital indicator with the range setting switch (push button)(4)
|
Lightning protector | A | Transmitter power supply voltage: 10.5 to 32 V DC (10.5 to 30 V DC for intrinsically safe type.) Allowable current: Max. 6000 A (1??40 ??s), Repeating 1000 A (1??40 ??s) 100 times Applicable Standards: IEC 61000-4-4, IEC 61000-4-5 |
The ??#??marks indicate the construction materials conform to NACE material recommendations per MR0175/ISO15156. Please refer to the latest standards for details. Selected materials also conform to NACE MR0103.
The ????? marks indicate the most typical selection for each specification.
- Only with aluminium or stainless steel field housing.
- Cast version of 316 SST. Equivalent to SCS14A.
- Hastelloy C-276 or ASTM N10276.
- Estimated Lead Time: 6 - 8
- Shipping Weight: 8 Kg
