CB-100 H2O2 Hydrogen Peroxide Gas Sensor 1100 mbar Highly Sensitive

Product Description
H2O2/CB-100 Hydrogen Peroxide Gas Sensor Highly Sensitive H2O2 Measurement



H2O2 Gas Sensor in Compact Housing
Key Features
• Highly sensitive H2O2 measurement
Applications
• Discontinuous Measurement
• Sterilization Process
• Disinfection monitoring



Performance data recorded at 20 – 25 °C, 30 - 50% RH, 900 - 1100 mbar


For further information about usage of Membrapor sensors, see application note MEM1.

The data contained in this document is for guidance only. Membrapor AG accepts no liability for any consequential losses, injury or damage resulting from the use of this document or from any omissions or errors herein. Customers should test under their own conditions to ensure that the sensors are suitable for their own requirements.



Specifications:

Rec. Load Resistor 10 - 33 Ω
Bias (V_Sense-V_Ref) +50 mV 2)
Relative Humidity Range 15 % to 90 % RH non-condensing
Temperature Range -20 °C to 50 °C
Pressure Range Atmospheric
Pressure Coefficient N.D.
Humidity Effect None
Warranty Period 12 months from date of dispatch
