C10807 R2868 Flame Detector module Suporting Development Board

Product Description
C10807 R2868 Flame Detector Module Suporting Development Board



C10807 Flame Detector Driver Panel



Features:

Uv TRON uses the photoelectric effect of metal and the gas multiplication effect to discover the source of Mars. It can detect 185 to 260 different narrow spectral sensitive sources. It has no sensitivity to visible light at all and does not need to filter any visible light (unlike a semiconductor detector). It has a small size and a wide range of sensitive angles (directivity), and can quickly and accurately detect the weakness emanating from the flame

Ultraviolet light (can detect a flame up to 5 m or the size of a cigarette point at a distance).

R2868 Technical specifications of flame sensor produced by HAMAMATSU Company

Compact UV Sensor with High Sensitivity and Wide Directivity,

Suitable for Flame Detectors and Fire Alarms.

Hamamatsu R2868 is a UV TRON ultraviolet detector that makes use of the photoelectric effect of metal and the gas multiplication effect. It has a narrow spectral sensitivity of 185 to 260 nm, being completely insensitive to visible light. Unlike semiconductor detectors, it does not require optical visible-cut filters, thus making it easy to use.

In spite of its small size, the R2868 has wide angular sensitivity (directivity) and can reliably and quickly detect weak ultraviolet radiations emitted from flame due to use of the metal plate cathode (eg. it can detect the flame of a cigarette lighter at a distance of more than 5 m.).

The R2868 is well suited for use in flame detectors and fire alarms, and also in detection of invisible discharge phenomena such as corona discharge of high-voltage transmission lines.



Specifications:

Range (ppm) 20
Linearity 0~5ppm linear: < + / - 0.5
Overload ppm 50
Temperature range -30~40 degrees
