Part Number: AV1121010Model: Pneumatic Positioner
Manufacturer: ABB
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
Ordering Information
Model | AV1 | Pneumatic Positioner |
Input signal | 1 | 0.2 to 1 bar (3 to 15 psi), standard temperature range ?C40 to 82 ??C (?C40 to 180 ??F) |
Stroke or rotary motion | 2 | 25.4 to 101.6 mm (1.0 to 4.0 in) or 90?? rotation |
Manifold / gage block | 1 | Manifold with equalizing valve, filters and gage ports (see Notes 1 and 2) |
Position transmitter | 0 | No position transmitter |
Drive shaft | 1 | 12.7 mm (0.500 in) square end (most common for 90?? actuators) |
Options | 0 | No options |
Notes.
- Required for double acting actuators with manual override (for example, UP or AC actuators).
- Not available with input signal codes 5 and 6.
- Estimated Lead Time: 4 - 6
- Shipping Weight: 5 Kg
