Home :: Rosemount Transmitter :: 3144PD1A1E5B4M5Q4 New Rosemount 3144P Temperature Transmitter

Product 461/1462

3144PD1A1E5B4M5Q4 New Rosemount 3144P Temperature Transmitter

$1,162.00 $734.00
Save: 37% off

Part Number: 3144PD1A1E5B4M5Q4

Model: 3144P Temperature Transmitter

Manufacturer: Rosemount

Specifications

Input: Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
Output Signal: 4-20 mA /HART® protocol, FOUNDATION? Fieldbus protocol
Housing: Dual-compartment field mount
Display/Interface: Large LCD display with percent range graph and buttons/switches
Diagnostics: Basic diagnostics, Hot Backup? capability, sensor drift alert, thermocouple degradation, min/max tracking
Calibration Options: Transmitter-sensor matching (Callendar-Van Dusen constants), custom trim
Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, hazardous location, marine type, see full specs for complete list of certifications

Features

Industry-leading accuracy and reliability for best performance in critical control and safety applications.
Transmitter-sensor matching improves measurement accuracy up to 75%.
5-year long-term stability extends calibration intervals to reduce trips to the field.
Rosemount X-well Technology measures temperature without a process penetration for reduced design, installation and maintenance costs.
