26PCDFG6G Force Sensor Board Interface Pressure Sensor 20PC

Product Description:

26PCDFG6G Force Sensor Board Interface Pressure Sensor 20PC



Features:

The patented conductive seal elastic connection system eliminates the traditional wire bonding and ribbon connection, increasing the measurement of the medium concurrently

Capacitive.

● The patented Snap-together structure leads to a variety of measurement hole forms

● Lowest price pressure sensor with temperature compensation and calibration in small package

● Different pin options (1x4 or 2X2)

● Can measure negative pressure and positive pressure

● Laser etching resistance to ensure excellent device consistency



Voltage - Power supply: 2.5V ~ 16V

Port size: male - 0.14" (3.56mm) tube

Port style: with barb

Characteristics: Temperature compensation

End style: PC pin

Maximum pressure: ±60PSI (±413.69kPa)

Operating temperature: -40°C ~ 85°C

Package/shell: 4-SIP module



Specifications:

Type of pressure compound
Working pressure ±30PSI (± 206.84kpa)
Output type Wheatstone bridge
Output 0mV ~ 100mV (10V)
Accuracy + / - 0.2%
