Home :: PLC & DCS :: 1784-CF128 New Allen Bradley CompactFlash Memory Cards

Product 602/5333

1784-CF128 New Allen Bradley CompactFlash Memory Cards

$333.00 $163.00
Save: 51% off

Part Number: 1784-CF128

Model: CompactFlash Memory Cards

Manufacturer: Allen Bradley

Condition: New & Original in Factory Packing

Factory Warranty: 12 Months

Technical Specifications

User available memory: 64 MB, 128 MB
Nonvolatile memory: Yes
Weight, approx.: 14.2 g (0.5 oz)
Temperature, operating:
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0 60??C (32 140??F)
Temperature, storage:
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40 85 ?C (-40 185??F)
Relative humidity:
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5 95% noncondensing
Vibration:
IEC 60068-2-6 (Test Fc, Operating):
2 g @ 10 500 Hz
Shock, operating:
IEC 60068-2-27 (Test Ea, Unpackaged Shock): 30 g
Shock, nonoperating:
IEC 60068-2-27 (Test Ea, Unpackaged Shock): 50 g
Emissions:
CISPR 11: Group 1, Class A
ESD immunity:
IEC 61000-4-2:
4 kV contact discharges
8 kV air discharges
Radiated RF immunity:
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80 2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 Mhz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 Mhz
1V/m with 1 kHz line-wave 80% AM from 2.0 2.7 GHz
