1771-IFE New Allen Bradley Analog Input Module

1771-IFE New Allen Bradley Analog Input Module

$1,371.00  $816.00
Save: 40% off


Part Number: 1771-IFE

Technical Specifications
  • Inputs per module: 16 single-ended; 8 differential low level
  • Module location: 1771 I/O rack - 1 slot
  • Input voltage ranges (nominal):
    +1 to +5V dc
    0 to 5V dc
    -5 to +5V dc
    -10 to +10V dc
    0 to +10V dc
  • Input current ranges (nominal):
    +4 to +20mA
    0 to +20mA
    -20 to +20mA
  • Resolution:
    12-bit binary
    12 bits plus sign on bipolar ranges
  • Accuracy: 0.1% of full scale range @ 25?C
  • Linearity: +1 LSB
  • Repeatability: +1 LSB
  • Isolation Voltage: +1500V, (transient)
  • Input overvoltage protection: 200V (voltage mode)?, 8V (current mode)?
  • Input overcurrent protection (current ranges): 30mA
  • Common mode voltage: +14.25 Volts
  • Input impedance: 100 Megohms for voltage ranges; 250 ohms for current ranges
  • Common mode rejection: 80 db, DC-120 Hz
  • Current Requirements: 0.75A @ +5V from I/O chassis backplane
  • Power Dissipation: 3.75 Watts (maximum)
  • Thermal Dissipation: 12.8 BTU/hr (maximum)
  • Unscaled BCD and binary output to processor:
    1000 to +409510 for polar ranges (0 to 5V, +1 to +5V, 0 to +20mA, and +4 to +20mA)
    -409510 to 409510 for bipolar ranges (?5V, ?10V, ?20mA)
  • Engineering units sent to processor: +999910 with selectable scaling
  • Internal scan rate:
    12.5 ms for 8 differential inputs (no digital filtering) -add 2.12ms for filtering
    25 ms for 16 single-ended input (no digital filtering) -add 4.24 for filtering
  • Environmental conditions:
    Operational temperature:     0 to 60?C (32 to 140?F)
    Storage temperature:     -40 to 85?C (-40 to 185?F)
    Relative humidity:     5 to 95% (without condensation)
  • Conductors:
    Wiring:     14 gauge stranded (max.); 3/64 inch insulation (max.)
    Category:     Category 2?
  • Keying: between 10 and 12; between 24 and 26
  • Field Wiring Arm Screw Torque: 7 9 inch pounds

  1. The inputs are protected to 200V. However, if an input terminal's voltage exceeds +14.25V as referenced to module common, channel to channel crosstalk can cause invalid input readings and invalid underrange/overrange bits.
  2. Only 8 volts can be placed directly across the input  when configured in the current mode.
  3. Refer to publication 1770-4.1, "Programmable Controller Wiring and Grounding Guidelines."

  • Availability: In Stock
  • Estimated Lead Time: Usually Ships in 5 - 7 Working Days
  • Shipping Weight: 2 Kg
