1771-IBD New Allen Bradley 1771 Digital DC Input Module

1771-IBD New Allen Bradley 1771 Digital DC Input Module

$498.00  $296.00
Save: 41% off


Part Number: 1771-IBD

Technical Specifications
  • Input per module: 16
  • Input Voltage Range: 10 to 30V dc
  • Minimum Input Current:
    4.5mA at 10V dc
    15mA at 30V dc
  • Minumum Off-state Current: 2.0mA @ 5V dc
  • Minimum On-state Voltage: 10V dc
  • Input Impedance: 2.2K ohms maximum
  • Input Signal Delay:
    Low to High propagation delay - 1ms
    High to Low propagation delay selectable - 1ms or 6ms
  • Power Dissipation: 7.3 Watts (max.), 1.0 Watts (min.)
  • Thermal Dissipation: 24.7 BTU/hr (max.), 3.4 BTU/hr (min.)
  • Backplane Current: 130mA @ 5V dc ?5%
  • Isolation Voltage: This isolation meets or exceeds the requirements of UL Standard 508, and CSA Standard C22.2 No. 142.
  • Environmental Conditions:
    Operational Temperature:     0? to 60?C (32? to 140?F)
    Storage Temperature:     -40? to 85?C (-40? to 185?F)
    Relative Humidity:     5 to 95% (without condensation)
  • Conductors:
    Wire Size:     14 gauge (2mm?) stranded maximum; 3/64 inch (1.2mm) insulation maximum
    Category:     1?
  • Keying: Between 10 and 12; Between 16 and 18
  • Wiring Arm Screw Torque: 7-9 inch-pounds
  • Agency Certification (when product or packaging is marked):
    CSA certified
    CSA Class I, Division 2, Groups A, B, C, D certified
    UL listed
    CE marked for all applicable directives

  1. Refer to publication 1770-4.1, Programmable Controller Wiring and Grounding Guidelines.

  • Availability: In Stock
  • Estimated Lead Time: Usually Ships in 5 - 7 Working Days
  • Shipping Weight: 2 Kg
