1769-L33ER New Allen-Bradley CompactLogix 5370 Ethernet Controller, 2MB Memory

1769-L33ER New Allen-Bradley CompactLogix 5370 Ethernet Controller, 2MB Memory

$1,390.00  $1,908.00
Save: -37% off


Manufacturer: Rockwell Automation
Part Number: 1769-L33ER
1769 CompactLogix L33ER Controller
Condition: New Original in Factory Packing
Factory Warranty: 12 Months

Specifications:

Model 1769-L33ER
User memory
1 MB
Optional nonvolatile memory

1784-SD1 card with 1 Gb of available memory (shipped with controller)
1784-SD2 card with 2 Gb of available memory (available for separate ordering)
Number of local expansion modules, max? Eight 1769 Compact I/O modules
Number of I/O module banks, max 3
Current draw @ 5V DC, controller power

500 mA
Current draw @ 24V DC, controller power 225 mA
Current draw @ 24V DC, field power, max

N/A
Power dissipation, max 4.5 W
Isolation voltage

30V (continuous), Basic Insulation Type, USB to system, Ethernet to system and Ethernet to Ethernet
Type tested at 500V AC for 60 s
Short circuit protection, field power N/A
Recommended external short circuit protection, field power N/A
Weight, approx

0.31 kg (0.68 lb)
Module width
55.00 mm (2.17 in.)

Module location DIN rail or panel mount
Panel-mounting screw torque 1.1 1.8 N m (10 16 lb in) - use M4 or #8 screws
Embedded power supply 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Power supply distance rating Controller and 1769-SDN: 4
1769 Compact I/O modules: 4 8, depending on module
Wire category?
2 - communication ports
Wire type, Ethernet

RJ-45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 24702
Wire type, power terminals and embedded I/O connections N/A
Wire size, power terminals?
N/A

Wire stripping length, power terminals? N/A
Screw torque, power terminals? N/A
Wire size, embedded I/O connections
N/A
Wire stripping length, embedded I/O connections N/A
North American temperature code T5
IEC temperature code T5
Enclosure type rating None (open-style)

You can use up to the maximum number of local expansion modules with the CompactLogix 5370 L1 controllers that are listed as long as the total current drawn by the embedded I/O and local expansion modules does not exceed both the available POINTBus backplane current of 1 A and the field power current of 3 A.
Use this Conductor Category information for planning conductor routing.
Regarding the CompactLogix 5370 L1 controllers, this specification applies to connecting wires to the power connector that is inserted in the controller.
