1769-IF4 New Allen Bradley 1769 Compact Analog Input Module

1769-IF4 New Allen Bradley 1769 Compact Analog Input Module

$750.00  $417.00
Save: 44% off


Part Number: 1769-IF4
Model: 1769 Compact Analog Input Module
Manufacturer: Allen Bradley
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months

Model1769-IF4
Inputs4 differential or single-ended
Input range





?10V
0...10V
0...5V
1...5V
0...20 mA
4...20 mA

Full scale range(1)

?10.5V
-0.5..10.5V
-0.5...5.25V
0.5...5.25V
0...21 mA
3.2...21 mA
Current draw @ 5.1V120 mA
Current draw @ 24V60 mA
Heat dissipation, max2.52 W
Converter typeDelta Sigma

Resolution(2)

14 bits (unipolar); 14 bits plus sign (bipolar)

Rated working voltage(3)

30V AC/30V DC

Common mode voltage range(4)

?10V DC max per channel
Common mode rejection> 60 dB @ 50 and 60 Hz with the 16 Hz filter selected
Input impedance

Voltage: 220 kCurrent: 250 k

Accuracy(5)

Voltage: ?0.2% full scale @ 25 ?C (77 ?F)
Current: ?0.35% full scale @ 25 ?C (77 ?F)
Accuracy drift with temperatureVoltage: ?0.003% per ?C
Current: ?0.0045% per ?C
Nonlinearity?0.03%

Repeatability(6)

?0.03%
Module errorVoltage: ?0.3%
Current: ?0.5%

Overload at input terminals, max(7)

Voltage: ?30V DC continuous, 0.1 mA
Current: ?32 mA continuous, ?7.6V DC
Isolation voltage

500V AC or 710V DC for 1 minute (qualification test), group to bus
30V AC/30V DC working voltage (IEC Class 2 reinforced insulation)
Weight, approx300 g (0.65 lb)
Dimensions (HxWxD), approx

118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Height with mounting tabs 138 mm (5.43 in.)
Slot width1
Module locationDIN rail or panel mount

Optional 24V DC Class 2 power supply voltage range(8)

20.4...26.4V DC
Power supply distance rating8 modules
Terminal screw torque

0.68 N m (6 lb in)

Retaining screw torque0.46 N m (4.1 lb in)
Wire size(22 14 AWG) solid; (22 16 AWG) stranded
Wire typeCu-90 ?C (194 ?F)
Replacement terminal block1769-RTBN18 (1 per kit)
Replacement door label1769-RL2 series B (2 per kit)
Replacement door1769-RD (2 per kit)


  • Availability: In Stock
  • Estimated Lead Time: Ships in 1 - 7 Working Days
  • Shipping Weight: 2 Kg
