Part Number: 1762-IF4Type: MicroLogix 4 Point Analog Input Module
Brand: Allen Bradley
General Specifications
- Dimensions, HxWxD: 90 x 40.4 x 87 mm (3.54 x 1.59 x 3.43 in.)
- Approximate shipping weight (with carton): 235 g (8.28 oz)
- Bus current draw, max: 40 mA @ 5V DC; 50 mA @ 24V DC
- Analog normal operating range: Voltage: -10 10V DC; Current: 4 20 mA
- Full scale? analog ranges: Voltage: -10.5 10.5V DC; Current: -21 21 mA
- Resolution: 15 bits (bipolar)
- Repeatability?: ?0.12%
- Input group to system isolation: 30V AC/30V DC rated working voltage? (IEC Class 2 reinforced insulation) type test: 500V AC or 707V DC for 1 min
- Module power LED: On: indicates power is applied.
- Recommended cable: Belden 8761 (shielded)
- Vendor ID code: 1
- Product type code: 10
- Product code: 67
- Wiring category4: 2 - on signal ports
- Pilot duty rating: Not rated
- Enclosure type rating: IP20
- North American temp code: T3C
NOTE:
- The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues to convert the analog input up to the maximum full scale range.
- Repeatability is the ability of the input module to register the same reading in successive measurements for the same input signal.
- Rated working voltage is the maximum continuous voltage that can be applied at the terminals with respect to earth ground.
- Use this Conductor Category information for planning conductor routing.
