Part Number: 1756-L82EModel: ControlLogix 5580 Controller
Manufacturer: Allen Bradley
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months
ControlLogix 5580 Controller Features
| Feature |
1756-L85E |
| Controller tasks |
32 tasks
1000 programs/task
Local I/O event triggers: No limit |
| Built-in communication ports(1) |
1-port USB(2)
Embedded Ethernet port |
| USB port communication |
USB 2.0
Full speed (12 Mbps)
Programming, configuration, firmware update, and online edits only |
| Ethernet performance |
10/100/1000 Mbps |
| I/O Capacity (Class 0/1) - packets/second(3)(4) |
128,000 without CIP Security? 40,000 with integrity 20,000 with integrity and confidentiality |
| Message Rate Capacity HMI/MSG (Class 3) -
messages/second(3)(4) |
2000 without CIP Security
1500 with integrity
900 with integrity and confidentiality |
| Communication options |
EtherNet/IP?
ControlNet®
DeviceNet®
Data Highway Plus?
Remote I/O
SynchLink?
Third-party process and device networks |
| EtherNet/IP nodes supported max(5) |
80 node(6)
175 node(7) |
| Network connections, per network module located in
the local chassis |
ControlLogix 5580 Controllers front EtherNet/IP port. See ??EtherNet/IP nodes supported, max?? in this table.
256 EtherNet/IP; 128 TCP (1756-EN2x)
128 EtherNet/IP; 64 TCP (1756-ENBT)
100 ControlNet (1756-CN2/A)
40 ControlNet (1756-CNB/D, 1756-CNB/E)
128 ControlNet (1756-CN2/B) |
- With Studio 5000 Logix Designer Application Version 28 or greater.
- The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
- I/O numbers are maximums; they assume no HMI/MSG. HMI/MSG numbers are maximums, they assume no I/O. Maximums assume the processor is the target, not the originator. Packet
rates vary depending on packet size. For more details, see Troubleshoot EtherNet/IP Application Technique, publication ENET-AT003, and the EDS file for a specific catalog number.
- For information on integrity and confidentiality, see the CIP Security with Rockwell Automation Products Application Technique, publication SECURE-AT001.
- A node is an EtherNet/IP device that you add directly to the I/O configuration, and counts toward the node limits of the controller. For more information on EtherNet/IP nodes, see the
ControlLogix 5580 Controllers User Manual, publication1756-UM543.
- With Studio 5000 Logix Designer application version 29.00.02.
- With Studio 5000 Logix Designer application version 30.00.00 or later.
- Availability: In Stock
- Estimated Lead Time: Ships in 1 - 7 Working Days
- Shipping Weight: 2 Kg
