Home :: PLC & DCS :: 1756-L72 New Allen Bradley ControlLogix 5570 Controller

Product 419/5332

1756-L72 New Allen Bradley ControlLogix 5570 Controller

$9,236.00 $4,526.00
Save: 51% off

Part Number: 1756-L72

Model: ControlLogix 5570 Controller

Brand: Allen Bradley

Condition: New & Original in Factory Packing

Factory Warranty: 12 Months

Model		1756-L72
User memory		4 MB
I/O memory		0.98 MB
Optional nonvolatile memory storage		1 GB (1784-SD1 ships with every controller) 2 GB (1784-SD2)
Digital I/O, max		128,000
Analog I/O, max		4000
Total I/O, max		128,000
Energy storage module		1756-ESMCAP capacitor energy storage module (removable, ships installed with every controller) 1756-ESMNSE capacitor energy storage module (removable, no residual WallClockTime power backup) 1756-ESMNRM capacitor energy storage module (nonremovable, secures controller by preventing USB connection an d SD card use)
Current draw @ 1.2V DC		5 mA
Current draw @ 5.1V DC		800 mA
Power dissipation		2.5 W
Thermal dissipation		8.5 BTU/hr
Isolation voltage		30V (continuous), basic insulation type, USB port-to-system Type tested at 500V AC for 60 s
USB port1		USB 2.0, full speed (12 Mbps)
Weight, approx		0.25 kg (0.55 lb)
Slot width		1
Module location		Chassis-based, any slot
Wire category2		3 - on USB port
North American temperature code		T4A
IEC temperature code		T4
Enclosure type rating		None (open-style)

The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.
Use this conductor category information for planning conductor routing as described in the system level installation manual.

Add to Cart:
