0522490 New Hengstler

Product Type Incremental Encoder
Series RI58
Voltage Rating 5V dc
Current Rating 40mA
Technology Optical
Number of Pulses 50
Shaft Type Solid
Shaft Size 6mm
Speed Rating 10000rpm
Frequency Rating 300 kHz (Pulse)
Connection Type Axial Cable
Mounting Type Synchro Flange Mount
IP Rating IP65
Cable Length 1.5m
Material Aluminium
Dimensions 58.5 mm (Dia.) x 82 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC
