0522282 New Hengstler

Product Type Incremental Encoder
Series RI58
Voltage Rating 10 to 30V dc
Current Rating 60 mA @ 10 V dc;30 mA @ 24 V dc
Technology Optical
Number of Pulses 2500
Shaft Type Solid
Shaft Size 10mm
Speed Rating 10000rpm
Frequency Rating 200 kHz (Pulse)
Connection Type Radial Cable
Mounting Type Clamping Flange Mount
IP Rating IP65
Cable Length 1.5m
Material Aluminium
Dimensions 58.5 mm (Dia.) x 79.5 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC
