0521691 New Hengstler

Product Type Incremental Encoder
Series RI42
Voltage Rating 10 to 30V dc
Current Rating 30 mA @ 24 V dc
Technology Optical
Number of Pulses 1024
Shaft Type Solid
Shaft Size 6mm
Speed Rating 10000rpm
Frequency Rating 200 kHz (Pulse)
Connection Type Axial Cable
Mounting Type Pilot Flange Mount
IP Rating IP64
Cable Length 10m
Material Plastic;Aluminium (Shaft)
Dimensions 40 mm (Dia.) x 63.3 mm (W)
Operating Temperature Range 0 to +60°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC
