0521682 New Hengstler

Product Type Incremental Encoder
Series RI41
Voltage Rating 10 to 30V dc
Current Rating 60 mA @ 10 V dc;30 mA @ 24 V dc
Technology Optical
Number of Pulses 500
Shaft Type Solid
Shaft Size 6mm
Speed Rating 10000rpm
Frequency Rating 200 kHz (Pulse)
Connection Type Radial Cable
Mounting Type Pilot Flange Mount
IP Rating IP40
Cable Length 5m
Material Aluminium
Dimensions 40 mm (Dia.) x 40 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC
