0521558 New Hengstler

Product Type Incremental Encoder
Series RI36-O
Voltage Rating 5V dc
Current Rating 40mA
Technology Optical
Number of Pulses 2000
Shaft Type Solid
Shaft Size 6mm
Speed Rating 10000rpm
Frequency Rating 300 kHz (Pulse)
Connection Type Axial Cable
Mounting Type Synchro Flange Mount
IP Rating IP64
Cable Length 15m
Material Aluminium
Dimensions 36.6 mm (Dia.) x 69.45 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC
