0521421 New Hengstler

Product Type Incremental Encoder
Series RI36-O
Voltage Rating 10 to 30V dc
Current Rating 60 mA @ 10 V dc;30 mA @ 24 V dc
Technology Optical
Number of Pulses 360
Shaft Type Solid
Shaft Size 6mm
Speed Rating 10000rpm
Frequency Rating 200 kHz (Pulse)
Connection Type Radial Cable
Mounting Type Pilot Flange Mount
IP Rating IP64
Cable Length 1.5m
Material Aluminium
Dimensions 36.6 mm (Dia.) x 42.5 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC
