0520240 New Hengstler

Product Type Incremental Encoder
Series RI30
Voltage Rating 10 to 30V dc
Current Rating 60 mA @ 10 V dc;30 mA @ 24 V dc
Technology Optical
Number of Pulses 50
Shaft Type Solid
Shaft Size 5mm
Speed Rating 10000rpm
Frequency Rating 200 kHz (Pulse)
Connection Type Axial Cable
Mounting Type Pilot Mount
IP Rating IP64
Cable Length 1.5m
Material Aluminium
Dimensions 30.4 mm (Dia.) x 65.3 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC;UL Listed
