0520185 New Hengstler

Product Type Incremental Encoder
Series RI30
Voltage Rating 5V dc
Current Rating 40mA
Technology Optical
Number of Pulses 400
Shaft Type Solid
Shaft Size 5mm
Speed Rating 10000rpm
Frequency Rating 300 kHz (Pulse)
Connection Type Radial Cable
Mounting Type Pilot Mount
IP Rating IP64
Cable Length 1.5m
Material Aluminium
Dimensions 30.4 mm (Dia.) x 42.5 mm (W)
Operating Temperature Range -10 to +70°C
Standards Met CE Certified;cULus Listed;RoHS 2002/95/EC;UL Listed
